DOWNLOAD SPEC SHEETS   SPL-6K SPECS Lumens output 6,000 Lumens Efficiency 230lm/W Solar panels Monocrystalline silicon, 22.8V/ 81W Battery 18V, 360Wh Solar charging time ≤ 5.1H Charge life 3 days Material Aluminium PC IP rating IP65 IK rating IK08 Dimensions Light head: 592.39 x 251.33 Panel: 880 x 585 Optimal mounting height 6m Weight Main body: 13kg Light head: 2.7kg LED colour temp 3000K in rainy weather 5700K in dry conditions PIR sensor range 120 degrees, 12m Remote control Optional Suitable pole or spigot diameter 60mm OD SPL-8K SPECS Lumens output 8,000 Lumens Efficiency 230lm/W Solar panels Monocrystalline silicon, 22.8V/ 101W Battery 18V, 450Wh Solar charging time ≤ 5.1H Charge life 3 days Material Aluminium PC IP rating IP65 IK rating IK08 Dimensions Light head: 592.39 x 251.33 Panel: 880 x 585 Optimal mounting height 8m Weight Main body: 13.5kg Light head: 2.7kg LED colour temp 3000K in rainy weather 5700K in dry conditions PIR sensor range 120 degrees, 12m Remote control Optional Suitable pole or spigot diameter 60mm OD SPL-10K SPECS Lumens output 10,000 Lumens Efficiency 230lm/W Solar panels Monocrystalline silicon, 22V/ 128W Battery 18V, 540Wh Solar charging time ≤ 4.8H Charge life 3 days Material Aluminium PC IP rating IP65 IK rating IK08 Dimensions Light head: 592.39 x 251.33 Panel: 880 x 743 Optimal mounting height 10m Weight Main body: 16.6kg Light head: 2.7kg LED colour temp 3000K in rainy weather 5700K in dry conditions PIR sensor range 120 degrees, 12m Remote control Optional Suitable pole or spigot diameter 60mm OD SPL-12K SPECS Lumens output 12,000 Lumens Efficiency 230lm/W Solar panels Monocrystalline silicon, 22V/ 154W Battery 18V, 675Wh Solar charging time ≤ 5H Charge life 3 days Material Aluminium PC IP rating IP65 IK rating IK08 Dimensions Light head: 592.39 x 251.33 Panel: 880 x 880 Optimal mounting height 12m Weight Main body: 18.7kg Light head: 2.7kg LED colour temp 3000K in rainy weather 5700K in dry conditions PIR sensor range 120 degrees, 12m Remote control Optional Suitable pole or spigot diameter 60mm OD SPL-15K SPECS Lumens output 15,000 Lumens Efficiency 230lm/W Solar panels Monocrystalline silicon, 22V/ 154W Battery 18V, 810Wh Solar charging time ≤ 6H Charge life 3 days Material Aluminium PC IP rating IP65 IK rating IK08 Dimensions Light head: 592.39 x 251.33 Panel: 880 x 880 Optimal mounting height 15m Weight Main body: 19.5kg Light head: 2.7kg LED colour temp 3000K in rainy weather 5700K in dry conditions PIR sensor range 120 degrees, 12m Remote control Optional Suitable pole or spigot diameter 60mm OD LIGHTING MODES MODE 1: 30% brightness all night with 100% brightness PIR activated light. MODE 2: 100% brightness for the first 5 hours of the night, then 25% brightness for the next 5 hours with 100% brightness PIR activated light, then 70% brightness until dawn. MODE 3: 70% constant brightness from dusk until dawn. PIR activated light duration: 30 seconds APPLICATIONS Driveway Carpark Roadway Pathway SOLAR LIGHTING TECHNOLOGIES ALS: Adaptive Lighting System Innovative patented technology that automatically adjusts lighting levels according to surrounding weather conditions without impacting passer-by visibility. ALS maximises battery efficiency and life of charge (redundancy). VFT: Variable Frequency Technology Special Technology managing LED output thereby maximising battery charge life. TCS: Temperature Control System Provides critical battery control system to protect the battery from overheating thus maximising battery life and output. PRODUCT CODES SPL-6K, SPL-8K, SPL-10K, SPL-12K, and SPL-15K
