DescriptionThe VX1000 Pro All-in-One Controller offers stable transmission, high-resolution handling, and flexible signal routing for complicated display systems.The VX1000 Pro has 10 Gigabit Ethernet ports and supports three different modes of operation: ByPass mode, fiber conversion mode, and video control mode. The unit can handle up to 6.5 million pixels, with a maximum output width of 10,240 pixels and height of 8192 pixels. This makes it perfect for LED setups that are very wide or very tall.The VX1000 Pro supports 4K2K@60Hz video signals and layer-based content management with up to 6 layers. The device makes sure that images are always the same on large-format LED walls by allowing for scaling, low-delay transmission, and pixel-level brightness and chroma correction.Access control is flexible. The tough enclosure design supports reliable operation in complicated live environments like stage events and professional rental systems.Main FeaturesA lot of different input optionsThere are two HDMI 1.3 ports, one HDMI 2.0 port (IN & LOOP), and one 10G optical fiber port (OPT 1).1x 3G-SDI (IN and LOOP)1 USB 3.0 port for playing mediaInterfaces for outputPorts for 10 Gigabit Ethernet.Two 10G fiber outputs1 monitor with a 3D interface and HDMI 1.3.Connecting AudioAudio built into HDMI is supported.One 3.5mm audio input1 audio output 3.5 mmControl the volume of the output.SyncSupports cascading alignment through internal source sync or an external Genlock signal.Managing EDID FilesYou can import and export EDID configuration files.Storing PresetsYou can make up to 256 presets.Loading presets with one buttonOverwrite and get rid of preset choices.You can see a preview of the layer.Layer ResourcesAllows for 6x2K×1K layer resources.There are three layer specifications: 4K×2K, 4K×1K, and 2K×1K.Scaling for the layerAdjustable Layer PositionLayer priority that can be setModifying the aspect ratio is supported!Works with 3DWorks with Ethernet-based emitter solutions.3D connectors let third-party emitters work with it.Scaling ImagesMode for full screen.Mapping from one pixel to another.Setting up custom scalingProcessing VideoAlgorithm for scaling without stepsOne click to go full screenIndependent cropping of input.Control of ColorChange the brightnessAdjusting the ContrastRegulation of SaturationChange of hueCalibration at the Pixel Level.Correction of brightness for each pixel.Color correction for each pixelCompatibility with calibration softwareCheck to see if the display can show test images.Playing media from USBFor single-partition USB drives, NTFS, FAT32, and exFAT are supported.The highest resolution for playback is 3840×2160.JPG, JPEG, PNG, and BMP are all types of image files.MP4 is the video format.H.264 and H.265 are video codecs.The highest H.264 resolution is 3840×2160 at 30 frames per second.The highest H.265 resolution is 3840×[email protected] is the audio codec.Upgrades to USB firmware are supported. The resolution of the USB input is always 1920×[email protected] for electricity:The voltage that goes into the device is 100–240V at 50/60Hz.Power consumption rating: 43 watts.The environmentThe temperature can be anywhere from 0°C to 50°C.Humidity: 5% to 85% RH, no condensationPlace to StoreThe temperature range is from -10°C to 60°C.Humidity that doesn’t condense can be anywhere from 5% to 95%.Specifications for the bodyThe size is 48.26 cm x 30.22 cm x 5.01 cm.Weight: 3.9 kgWeight in total: 6.5 kilogramsInformation about packing:The case is 54.5 cm long, 42.5 cm wide, and 14.5 cm high.The size of the packing box is 56.5 cm x 45 cm x 17.5 cm.Accessories that come with itOne power cordOne Ethernet cable1 HDMI cable2 silicone dust plugsOne USB cableThe package comes with one Phoenix connector, one quick start guide, and one certificate.
