DescriptionThe NovaStar VX1000 is an LED display controller that combines image processing and sending signals into one unit. A single NovaStar VX1000 can handle up to 6.5 million pixels. The NovaStar VX1000 is good for installing ultra-wide and large-format LED screens.The system can take in signals in a number of formats, such as HDMI, DVI, 3G-SDI, and optical transmission. It can handle 4K×1K@60Hz content and lets you scale up or down smoothly without fixed steps. Low-delay transmission, 3D playback, pixel-level brightness correction, and pixel-level chroma adjustment are some of the other processing features.The NovaStar VX1000 works with NovaLCT and V-Can software for advanced management. This lets you set up screens, manage presets, upgrade firmware, set up redundancy, and do remote diagnostics. The device can back up at the device level, have redundant Ethernet ports, back up input sources, sync with external signals, and send optical signals over long distances. The NovaStar VX1000 is made for rental staging, fine-pitch LED walls, and mid- to high-tier event systems. It comes in a standard 19-inch rack form factor for structured installation environments.Input Ports1pc 3G-SDI (up to 1920×1080@60Hz, supports deinterlacing, and has 1pc loop output)Two HDMI 1.4 ports that can handle up to 3840×1080@60Hz or 3840×2160@30Hz and are HDCP 1.4 compliant2 DVI ports (compatible with HDMI 1.4 and able to show the same resolution as HDMI)Custom resolution support for widths up to 4092 pixels or heights up to 3981 pixelsHDMI and DVI don’t support interlaced signals.Interfaces for Output10 Gigabit Ethernet output ports1 HDMI 1.3 monitoring output (default 1920×1080@60Hz) 2 optical ports (OPT 1 adaptive I/O, OPT 2 output only in Copy or Backup mode)Transmission by LightSingle-mode module: 1310 nm wavelength, up to 10 km awayMulti-mode module: 850 nm wavelength, up to 300 m awayThe transmission rate is between 9.95 and 11.3 Gbit/s.Main FunctionsScaling output without stepsTransmission with low latency (as low as 1 frame in some cases)Support for 3D playback (output capacity is cut in half when this is turned on)Control of layers: Layer 1 PIP 1 PIP 2Save, load, copy, and clear presetsImage mosaic for splicing on multiple devicesBackup of devices and extra portsHot backup of the input sourceInput and loop for genlock synchronizationAudio output through a multifunction cardSpecifications for electricityInput voltage: 100–240 V~, 1.6 A, 50/60 HzRated power use: 28 WThe temperature range for operation is 0°C to 45°C.Humidity levels for operation: 20% to 90% RH, no condensationStorageThe temperature for storage is between –20°C and 70°C.Humidity in storage: 10% to 95% RH, not condensingSpecifications for the bodySize: 48.36 cm × 35.12 cm × 5.01 cmThe net weight is 4 kg.Level of noise: 45 dB (normal at 25°C)
