DescriptionThe V760 is an integrated LED control system that uses hardware to combine screen management and image processing into one physical device. The V760 makes on-site deployment easier by making the system less complicated while yet providing consistent signal processing and output performance. The V760 has an industrial-grade casing that makes it reliable in tough business settings including hotels, retail malls, exhibition halls, and broadcast studios.The V760 offers flexible display control and supports many different signal kinds. Users may easily change the size, position, and cropping of windows. You may quickly swap input channels using dedicated shortcut buttons. Audio input from external sources is supported independently. You may choose from a list of preset resolution settings or change them one at a time. You may choose from three ways to scale: full-screen expansion, pixel-to-pixel mapping, or a scaling adjustment that you can change.Quick screen mapping makes it easy to set up LED layouts quickly without having to use sophisticated methods. V760 features two Ethernet output ports that can handle up to 1,300,000 pixels at a time. You may store up to six user-defined display scenes as templates and get them back right away. You can alter things like brightness and gamma on the device itself. It is supported to integrate centralized control.Input Connections1pc DVI-D, compliant with VESA standards, HDCP 1.4, interlaced signal supported, 1pc HDMI 1.3, supporting up to 19201080@60Hz, 1pc VGA, supporting up to 19201080@60Hz, and 1pc CVBS, supporting PAL and NTSC formats.Supporting 1080p@30fps media playback, 1 USB 2.0 Type-ASupport for USB filesNTFS, FAT32, and FAT16 are all supported file systems. exFAT is not.JPG, JPEG, PNG, and BMP are all supported image formats.MPEG1, MPEG2, MPEG4, Sorenson H.263, H.264 (AVC1), H.265 (HEVC), RV30, RV40, DivX, and Xvid are all supported video codecs.AAC-LC, VORBIS, PCM, and FLAC are some of the audio codecs that are supported.Audio ConnectionsTwo ports for audio input and output.Interfaces for OutputThere are two Ethernet ports that connect to receiving cards.Control Interfaces1 RS232 port via Ethernet for connecting to the central control system.1 USB Type-B port for updating firmware and fixing problems with devicesElectrical Specifications:The input voltage is 100–240V AC @ 50/60Hz.Power use rating: 12 watts.The environment in which it worksThe temperature range for working is -20 to 60 degrees Celsius.Working humidity: 20% to 90% RH, no condensation.Physical DetailsThe size is 48.26 cm x 25.00 cm x 5.00 cm.Weight: 2.8 kgWeight of all five items in the package: 20 kg.Details about packing:The size of the box is 56.5 cm by 32.8 cm by 8.8 cm.The size of the outer carton (5 pieces) is 58.6 cm x 35.3 cm x 46.5 cm.The package comes with a power cord, a USB cable, a DVI cable, an HDMI cable, a brief guide, and certification papers.Video Input Features:It supports 8bit RGB 4:4:4 and 1920×[email protected] 1.3 supports 8bit YCbCr 4:4:4 resolutions up to 1920 x 1080 at 60Hz.HDMI 1.3 supports 8bit YCbCr 4:2:2 resolutions up to 1920 x 1080 at 60Hz.HDMI 1.3 supports 10bit RGB 4:4:4 and 1920 x 1080 at 60Hz.HDMI 1.3 supports 10bit YCbCr 4:4:4 and 1920 x [email protected] to 1920 x 1080@60Hz, HDMI 1.3 supports 10bit YCbCr 4:2:2 resolution.HDMI doesn’t work with YCbCr 4:2:0.12 bit input is not supported by HDMI.Up to 1920 x 1080@60Hz, DVI supports 8bit RGB 4:4:4 resolution.
