DescriptionThe NovaPro UHD Jr can handle resolutions of 4K×2K at 60Hz and ultra-wide 8K×1K at 60Hz. This makes it perfect for LED wall uses that need clear images and steady delivery. You can use V-Can smart management software with the NovaPro UHD Jr. This makes setup easier, gives you more control over image stitching, and helps things go more smoothly throughout deployment. Neutrik Gigabit Ethernet connections and high-speed optical fiber ports send data to LED cabinets in complicated ways, making sure that the data gets there safely.Main Features:1PC DP 1.2 inFour DVI inputs1 HDMI 2.0 input and loop outputTwo 12G-SDI inputs with loop output16 Neutrik Gigabit Ethernet outputs.4 outputs for 10G optical fiberMaximum load: 10,400,000 pixels.Maximum width: 16384 pixels.The highest point is 8192 pixels.There are three levels of support: one main layer and two PIP layers.With Armor series receiving cards, low-latency transmission may send two frames at once.Support for 3D mode (turning it on cuts the output capacity in half)Support for custom BKG (a solid color or photo background)You may scale the image in three ways: to fit the full screen, pixel by pixel, or to your own specifications.Background Use of the Input Capture FunctionCompatibility with V-CAN software controlYou may save up to 10 user presets.You can handle both custom and standard EDIDs.Controls on the Front PanelPress the power button to turn it on, and then hold it to turn it off.USB-B port for connecting to a PC for debugging.Dedicated buttons for switching between input sources, with LED lights to show the status.Built-in TFT screen for checking the system and using the menu.A knob that turns to change settings and navigate.The function keys include PIP, SCALE, DVI MOSAIC, and a FN button that you may change. Press the ESC button to quit or cancel.Input Ports on the BackIt works with DVI HDCP 1.4 and has two 12G-SDI inputs that work with the ST-2082-1, ST-2081-1, ST-424, and ST-292 standards.SDI may have resolutions between 4096×2160@60Hz and 3840×2160@60Hz, and it has one DP 1.2 input.It works with DP HDCP 1.3 and has one HDMI 2.0 input that can handle 3840×2160@60Hz. HDMI HDCP 2.2 compatible.Output Ports16 ports for Gigabit Ethernet output.Each port may load up to 650,000 pixels from an 8-bit source.10-bit/12-bit source, with a maximum of 320,000 pixels.4 × 10G optical ports (OPT 1–4)When all optical ports are on, you may use copy mode and hot backup.1 HDMI 2.0 loop output (supports 1-level cascade)Two 12G-SDI loop outputsOne HDMI monitor can show up to 1920×1080 @ 60Hz.Control Interfaces1 Ethernet control port1 × USB Type-B port for control1 USB Type-A connector for outputting photo mosaics1x GENLOCK INLOOP port for syncing.1x RS232 port for connecting to central control.Electrical Details:The input voltage may be between 100 and 240 volts, 50 and 60 hertz, and 2 amps.Power consumption rating: 70W.The place where you workThe temperature range for operating is 0°C to 45°C.Place to StoreThe temperature range for storage is -10°C to 60°C.Humidity in storage: 0–95% RH, no condensation.Specifications for the bodySize: 48.26 cm x 39.55 cm x 13.90 cm.Weight without packaging: 6.3 kgWeight: 13 kilogramThe average noise level at 25°C is 46 decibels (A).Information about packing:The dimensions of the packing box are 60.4 cm x 52.4 cm x 29.1 cm.The carrying case is 59.5 cm long, 27.5 cm wide, and 50 cm high.Accessories that come with it1 EU power cordOne power cable for the US and one for the UK.One Cat5e cableOne USB cableOne DVI cable1 HDMI cableA DP cable, a Quick Start Guide, a Packing List, a Customer Letter, and four silicone dust plugs are all included.Video Input Options:HDMI 2.0 and DP 1.2 can send 8-bit RGB 4:4:4 video at a resolution of 3840×2160 at 60Hz.8-bit YCbCr 4:4:4 at a maximum of 3840×[email protected] YCbCr 4:2:2 at 60Hz up to 3840×2160.10-bit RGB 4:4:4 resolution at 3840×[email protected] YCbCr 4:2:2 up to 60Hz at 3840×2160.Resolution of 12 bits RGB 4:4:4 up to 3840×[email protected] YCbCr 4:2:2 up to 3840×2160 at 60 Hz.There is no support for YCbCr 4:2:0.At 60Hz, S-DVI can handle 8-bit RGB 4:4:4 resolutions up to 1920×1080.D-DVI can handle 8-bit RGB 4:4:4 at up to 3840×[email protected] can handle up to 4096×2160 at 60Hz.
