DescriptionThe Colorlight Z5 is a professional-grade LED super processor designed for situations where real-time image fidelity and ultra-low latency are non-negotiable. It supports the requirements of big format LED control with complete 4K input compatibility across three interface types – HDMI 2.0, DisplayPort 1.2 and 12G-SDI – and delivers up to 13.1 million pixels of total output capacity. This combination makes the Z5 ideal for live events, broadcast venues, sports monitoring setups and film production stages where response time and image quality are crucial.The 3-layer display design allows operators to have up to three simultaneous windows of content — one 4K channel and two HD channels — with full support for cropping, scaling, splicing and window roaming. Processing is done with at least one frame latency, giving a near-instantaneous response for time-sensitive content contexts. The Z5 also supports HDR10 and HLG display standards, ensuring the wide color gamut and high dynamic range of source material is preserved through to compatible receiving cards.Connectivity is provided by 20pcs Gigabit Ethernet ports with Neutrik etherCON connectors, with the option for 2pcs 10 Gigabit fiber ports for long-distance transmission when used with appropriate optical transceivers. Single points of failure are minimized for mission critical deployments with support for both controller redundancy and Ethernet port redundancy. Management over the web is available through any browser, no extra software required. Control methods include USB, RS232 and TCP/IP over LAN for flexible integration with third party systems.Input Interfaces1x HDMI 2.0 IN1pc Display Port 1.2 (DP1.2) input1pc 12G-SDI InSingle port supports up to 4096 x 2160 @ 60HzSupports 8-bit and 10-bit video signal inputInput frame rate range: 23.98Hz – 240HzHDCP 1.4 & 2.2 SupportOutput Interfaces20pcs Neutrik etherCON Gigabit Ethernet Ports;2pcs 10Gbit fiber port output (optional, selectable instead of Ethernet)Output frame rate range: 23.98Hz to 240HzEthernet port redundancy supportedController redundancy supportedStandard compatible with professional optical transmitter for long distance transmissionVideo Input FeaturesMaximum single port input resolution: 4096 x 2160 @ 60HzSupports input of 8-bit video signalSupport for 10-bit video signal inputHDCP 1.4 copy protection supportedSupports HDCP 2.2 content protectionInput Frame Rate: 23.98Hz to 240HzKey FeaturesMaximum output pixel count: 13.1 megapixelsMaximum output width: 16,384 pixelsMax output height: 8192 pixels3-window display support — 1 channel 4K 2 channels HD at the same timeCropping, scaling and switching of broadcast quality videoWindow roaming and window splicingLow latency processing – at least 1 frame delaySupport for HDR10 displaysSupport for HLG displaysGenlock input and loop for screen sync between several devicesAdjust hue, saturation, contrast and brightnessRGB independent control of color temperature adjustmentGrouping network ports to adjust brightnessWeb-based device administration — No software installation necessary. Cross-OS compatibility2pcs USB ports for control and cascade (1pc PC/debug input, 1pc cascade output)RS232 port at 115200 baud for third party device integration
