DescriptionU6 Max is based on a 15-slot modular chassis supporting 22 types of boards, enabling integrators to scale a single chassis from a modest configuration to 130 million pixels of output. You can install up to 10 input boards and 5 output boards at the same time. The input board supports HDMI, DisplayPort, SDI, CVBS, VGA and IP signal types. U6 Max is suitable for stadiums, convention centers, big scale events, traffic monitoring, commercial displays.Output is 130 million pixels via 10G fiber, 118 million pixels over 5G Ethernet or 65 million pixels over 1G Ethernet. HDMI and DVI connections are available for LCD and projection screens. All devices support up to 80 layers, 4K HDR video with HDR10 and HLG, and 8-bit or 10-bit color in RGB, YCbCr444, YCbCr422, and YCbCr420 formats. Up to five different screen groups can be performed simultaneously, each with its own resolution and set of parameters, synced without tearing, delay or frame loss.Built-in redundancy across fiber, Ethernet and twin power sources, with real-time monitoring of device health, screen connection, temperature, humidity and bit error rate, with alerting via web, app and front panel. Dual 4K UHD preview and monitoring ports allow simultaneous input and output, and up to 10,000 presets can be saved and applied via the Kylin VICP app or cross-platform web interface. U6 Max also provides superior seam correction for LED walls and bezel adjustment for LCD video walls.Input InterfaceInput board U_2xHDMI 2.0 2xDP 1.2, 2 groups of ports, 4K capable1xU_1xHDMI 2.0 1xDP 1.2 input board for single group 4K inputU_2x12G-SDI input board (supports 6G-SDI, 3G-SDI, HD-SDI and SD-SDI)HD & SD signal source(U_4x3G-SDI input board)U_4xHDMI 1.3 or U_6xHDMI 1.3 input boards for 2K class sourcesU_4xDVI input board, supports SL-DVI and DL-DVI modesU_2xIP input board with network video decoding (H.264, H.265)Legacy analog sources like U_2xVGA 2xCVBS, U_4xVGA, and U_4xCVBS boardsUp to 10 input board slots throughout the chassisOutput InterfacesU_20x1G Ethernet output board, with the ability to load up to 13 million pixels per boardU_8x5G Ethernet output board, up to 23.6 million pixels per boardU_4x10G fiber output board, loading up to 26M pixels per boardU_2xHDMI 2.0 and U_1xHDMI 2.0 output boards for direct video display.U_4xDVI, U_4xHDMI 1.4 and U_6xHDMI 1.3 output boards for LCD or projection panelsSupports independent, redundant and copy operation modes for 10G fiber output boardUp to 5 output board slots available in chassisVideo Input FunctionalityDCI 4K (4096×2160) input up to 60Hz via HDMI, DP and SDI boards8-bit, 10-bit and 12-bit color depth depending on board typeColor formats : RGB, YCbCr444, YCbCr422, YCbCr420Frame rate range from 23.98Hz to 240Hz on compatible boardsSupport for HDR10 (SMPTE ST 2086/2084) and HLGHDCP2.2 and HDCP1.4 support for HDMI and DP boardSignal de-interlacing for 480i, 576i, 1080i sources supported2xIP board Decodes up to 8 channels 3840×2160@30Hz at the same timeMain FeaturesUp to 80 layers per device or 20x4K and 16x2K per boardFree splicing and layer traveling around the canvasFrame rate multiplication: auto and manual, plus fade in/out transitionsSupport for 3D displayUp to 5 independent screen groups with coordinated, tear-free stitchingAdvanced seam correction for LED wall, LCD wall bezel compensationBKG backdrop images up to 32768 pixels wide or tallCustom design and customizable transparency of scrolling graphics and text on OSDUp to 15 built-in advanced test patternsDual 4K UHD multiviewer preview and monitoringUp to 10,000 presets with real-time application and scheduled loopElectrical CharacteristicsPower supply: AC 100-240V 50/60HzTotal power consumption: 550 WMaximum power draw: 500WOne power supply included, second optional for redundancyDual power arrangement for uninterrupted 24/7 operationKeeps a redundant parameter snapshot over Ethernet, fiber and devicesOperating ConditionsOperating temperature range: 0°C to 50°C (32°F to 122°F)Operating humidity range: 0%RH to 85%RH non-condensingMin working temperature: 0C (32F)max working temperature: 50C (122F)Operating Humidity Minimum 0%RHMaximum humidity of operation 85%RHNoise level at 25C/77F: below 45 dB(A)Environmental StorageStorage temperature: -10C to 60C (14F to 140F)Storage humidity: 0%RH to 95%RH non-condensingMinimum storage temperature: -10C (14F)Maximum storage temperature: 60 °C (140 °F)Storage humidity : 0%RH (minimum)Max storage humidity: 95%RHPhysical Specifications:Width of device: 48.3cm (19.0″)Device height: 26.6 cm (10.5″)Device depth: 18.7″ (47.4cm) excluding rubber feetNet weight: 24.2kg (53.24lbs)Gross Weight: 31.7 kg (69.89 lbs)15-slot chassis that can hold up to 10 input and 5 output cardsHorizontal only placement – Do not invert or stand unit on endPacking DetailsPacking box width: 62.1cm (24.4″)Packing box height: 60.1cm (23.6 inch)Packing box depth: 42.0cm (16.5″)Shipping weight: 31.7kg (69.89 lbs)Net unit weight within pack: 24.2kg (53.24 lbs)Packaging for the complete 15-slot chassis configurationAccessories included1pc U6 Max splicer device for video1pc user manual1pc warranty card1pc certificate1pc Gigabit Ethernet Cable1 to 2pcs power cord, other cords for alternative power supply1pc cleaning brush1pc earth lead1 × HDMI 2.0 cable, plus additional cables for optional boards1pc DP 1.2 cable, extra cables for optional boards1pc DVI Cable, includes extra cables for alternative boards
